Korg Poly-61  •  Voice Board
KLM-476 Synth Voice Board (Old Production)
Korg Poly-61 - Top View * Left Side

Korg Poly-61 - Top View * Right Side

Korg Poly-61 - Twins * …

Korg Poly-61 - Panel Display * Program No., Parameter & Value Indicators

Korg Poly-61 - Logotype * …

Korg Poly-61 - Opened * Custom Built Wooden Case (not made by me…)

Korg Poly-61 - Processor Board * KLM-475 CPU Board (Old Production)
Next slide

Korg Poly-61 - Voice Board - Image by Nikolaus Riehm - Equipment courtesy of Wallysworld
Korg Poly-61 - Opened * Left Side (Keyboard Assembly Removed)

Korg Poly-61 - Opened * Right Side (Keyboard Assembly Removed)

Korg Poly-61 - Processor Board * KLM-509A CPU Board (New Production)

Korg Poly-61 - Voice Board * KLM-508A Synth Voice Board (New Production)

Korg Poly-61 - Processor Boards * Two KLM-509A CPU Boards with Corrosion due to Battery Leakage

Korg Poly-61 - Corrosion * Massive Corrosion on the Rear Panel (Jack Board Removed)

Korg Poly-61 - Processor Board * KLM-509A CPU Board - Mitsubishi M58981P-30: 4kBit SRAM
